Polyester-based TPU 3D Printing Service
Advantages of Polyester-based TPU 3D printing: Higher mechanical strength, wear resistance, and chemical corrosion resistance (especially oil resistance), suitable for high-load industrial scenarios. 3D printing enables complex mechanical structures (e.g., gears, seals) while retaining material tensile and tear resistance, with high surface precision. Widely used in automotive parts (e.g., wear-resistant bushings), aerospace lightweight components, and industrial flexible molds, balancing durability and design freedom.
Primary Benefits:
- Industrial Machinery Components
- Automotive & Transportation Parts
- Aerospace Lightweight Components
What do you want printed?
You can also send us 3D object files at our Email:Jerry.xiao@julyn.cn
TPU Material Properties
| Flexural Modulus | Abrasion Resistance | Tensile Stress | Tear Strength | Tensile Elongation (Break) | |
| Test Method | ASTM D790 | ASTM D1044 | ASTM D412 | ISO 34-1 | ASTM D412 |
| Texin 245D | 73F: 9,990 psi | 70 mg | 50% strain: 1,100 psi 100% strain: 1,310 psi | 700 lb/fin | 500% |
| 158F: 7,500 psi | 300% strain: 3,000 psi | ||||
| Texin 983A | -22F: 8,560 psi | 30 mg | 100% strain: 798 psi | 500 lb/fin | 670% |
| 73F: 3,900 psi | 300% strain: 1,200 psi |
3D-Printed TPU Part Dimensions
Maximum part size and minimum feature size will vary based on selected resolution. 3D-printed TPU is available in high, normal, and large format resolutions.
| Resolution | US | Metric | |
| Maximum Dimensions | High (20 um) | 3.8 in.x 3.8 in.x 3.7 in. | 98mm x98mm x94mm |
| Normal (30 um) | 9.6 in.x 9.6 in.x 13.0 in. | 244mmx244mmx330mm | |
| Large Format (40 um) | 31.5 in. x 15.7 in.x 19.7 in. | 800mmx398mm x500mm | |
| Minimum Feature Size | High (20 um) | 0.015 in. | 0.381mm |
| Normal (30 um) | 0.030 in. | 0.762mm | |
| Large Format (40 um) | 0.015 in. | 0.381mm |
How Does TPU 3D Printing Work?
First, design a 3D model in CAD and import it into slicing software to layer it into 0.05-0.1mm slices, generating support structures for complex shapes. The lifting platform immerses into the TPU resin tank, where UV laser/projector cures layers per sliced data. The platform lowers, repeating spreading and curing until completion. Post-printing, remove supports, clean surface resin with alcohol/agents, then cure in UV chamber to enhance elasticity, strength, and weather resistance. Suitable for flexible electronics, medical catheters, and precision optics.
